5/8"x30" w/ 4" Thread F1554 Grade 55 Straight Anchor Bolt Plain Finish
- Weight:
- 2.70 LBS
- Shipping:
- Calculated at Checkout
Bulk discount rates
Below are the available bulk discount rates for each individual item when you purchase a certain amount
| Buy 11 - 25 | and get $0.26 off |
| Buy 26 - 50 | and get $0.52 off |
| Buy 51 - 100 | and get $0.78 off |
| Buy 101 or above | and get $1.22 off |
Description
5/8"x30" Structural Anchor Bolt, and minimum 4" Thread Length.
Straight anchor bolts, meeting with ASTM standard F1554, are essential for securing structural supports like building columns and street lighting to concrete foundations. Featuring a threaded end for embedding into concrete, they ensure stability against lateral and vertical forces, providing reliable support for various applications. Some common applications for anchor bolts include Light Poles, Steel Building Columns, and Machinery Bases.
Click to view product data sheet here
| Material | F1554 Grade 55-S1 |
| Diameter (Min.) A | 0.5589" |
| Length B | 30" |
| Thread Size | 5/8"-11 |
| Thread Length C | 4" Min. |
| Thread Length D | 2" Min. |
| Anchor Type | Straight(I) |
| Thread | Right Hand, UNC Course Thread Class 1A |
| Included Hardware | 2 Finish Nuts, 2 Flatwashers |
| Country of Origin | Bolts: United States, Hardware: Non-Domestic |
*Anchor Bolts are roll threaded per the F1554 Standard, bolt body will be undersized per the standard (Min. of .5589")
Diameter (A): |
5/8" |
Overall Length (B): |
30" |
Top Thread Length (C): |
6" Minimum |
Bottom Thread Length (D): |
2" Minimum |
Material: |
F1554 Grade 55-S1 |
Finish: |
Plain Steel |
Threads: |
5/8"-11 UNC |
country of origin: |
Bolts: United States, Hardware: Non-Domestic |
